Place of Origin:
Shanghai
Brand Name:
Weixuan
Certification:
CE,ISO
Model Number:
WX35
Unpacking:
After unpacking the unit, carefully inspect unit for any damage that may have occurred during transit. Check for any loose, missing, or damaged parts.
Technical data
| Model | WX35 |
| Refrigeration capacity |
3500W/11900BTU |
| Voltage /Cycle | 220VAC/50Hz |
| Power consumption | 1.4KW |
| Air Volume | 470m³/h |
| Refrigerant | R410A |
| Noise | 50-55db |
| Working temperature | 18-45℃ |
| Size | 450 * 510 *1100mm |
| Weight | 60kg |
| Outlet pipe | 2 |
Maintenance
FILTER CLEANING
There are two fi lters in the unit. The evaporator fi lter is located at the front of the unit. The condenser fi lter is located at the side of the unit.
1. loosen up 2 bolts on the front fi lter guard.
2. Slide fi lter up and use a vacuum cleaner to remove the dust from the fi lter.
3. If the fi lter is heavily covered with dust and dirt, warm water and mild soap or neutral detergent may be used to wash the fi lter.
4. Replace the clean fi lter and close the fi lter guard.
5. To clean the condenser fi lter, lift up on the side fi lter from the middle bar slightly and then angle the fi lter outwards from the bottom and remove.
6.Use the same cleaning procedure as above (3 – 5).
FAQ
1. Are you manufacturer or trade company?
We are professional manufacturers and have done this business for many years.We have a big factory, which is in Shanghai. Welcome to visit our factory any time.
2. What is your main products?
We mainly produce Spot Air Cooler, Portable Air Coolers, Industrial Spot Coolers Commercial Spot Coolers, ect
3. Can you customize multiple size products ?
Yes,we have special technology and know-how technology, which can produce as customers' requirements.
4. Any Certificates?
We passed CE,ISO,etc.
5. What is your delivery time?
We can make prompt delivery for products in stock. As for customized products or large quantity products, our delivery time is normally 5-8 working days or as your requirement.
