Place of Origin:
Shanghai
Brand Name:
Weixuan
Certification:
CE,ISO
Model Number:
WX35
Features:
1.high quality compressor
2.powerful cooling
3.spot cooling by flexible cooling arms
4.digital control
5.metal filter
6. decrease in drain
7. Snug to wall: Can be placed close to the wall on three sides.
8. Air filter: Easy-to-clean air filter.
9. Durable filter: Large surface area, with no necessary to be frequently maintained.
10. Built-in auto swing mechanism: An auto swing mechanism is built in the unit.
Technical data:
| Model | WX35 |
| Refrigeration capacity |
3500W/11900BTU |
| Voltage /Cycle | 220VAC/50Hz |
| Power consumption | 1.4KW |
| Air Volume | 470m³/h |
| Refrigerant | R410A |
| Noise | 50-55db |
| Working temperature | 18-45℃ |
| Size | 450 * 510 *1100mm |
| Weight | 60kg |
| Outlet pipe | 2 |
1. Wherever our customers, sales associates and suppliers come into contact with us, we try to make the dialogue pleasant and profitable for both sides.
2. open ear for questions or problems.
3. Good, understandable technical documentation.
4. Short delivery times for machinery, spares and wear parts.
5. Friendly competent staff.
6. Fair pricing.
Maintenance
There are two filters in the unit. The evaporator fi lter is located at the front of the unit. The condenser fi lter is located at the side of the unit.
1. loosen up 2 bolts on the front filter guard.
2. Slide filter up and use a vacuum cleaner to remove the dust from the fi lter.
3. If the filter is heavily covered with dust and dirt, warm water and mild soap or neutral detergent may be used to wash the fi lter.
4. Dry the filter in a shaded area before replacing it. Do not operate the unit without the filter installed and the filter guard in the closed position.
5. To clean the condenser fi lter, lift up on the side fi lter from the middle bar slightly and then angle the fi lter outwards from the bottom and remove.
6. To replace the condenser fi lter, place the top of the fi lter in the guide and slide the fi lter up until the bottom of the fi lter clears the frame. Then push the bottom of fi lter into the guide and let fi lter gently fall inside the guide.
