WXWSCT-7 Water Cooled Split Unit 24000 BTU Ductless AC

WXWSCT-7 Water Cooled Split Unit: 24,000 BTU Ductless Portable AC Solution

The WXWSCT-7 Water Cooled Split Unit revolutionizes portable cooling with its innovative ductless design, delivering powerful 7KW (24,000 BTU) performance for industrial and commercial spaces. Unlike traditional air-cooled units that waste energy by exhausting indoor air, this split system transfers heat via a sealed water/glycol loop to an outdoor unit, preserving indoor air quality and slashing energy costs by 30%. Ideal for server rooms, kitchens, workshops, or temporary sites, it requires zero ductwork—simply connect the indoor and outdoor units with insulated hoses (max 20m) for instant cooling.

Key Features & Advantages

1. True Ductless Efficiency:

   • No window vents or complex installations.

   • Recirculates 100% indoor air, eliminating humidity loss and energy waste.

2. Industrial-Grade Cooling:

   • 24,000 BTU capacity cools large spaces (up to 80m²) instantly.

   • Dual modes: Recirculation (air filtration) and Air-Conditioning (thermostat control from 8°C–35°C).

3. Energy & Cost Savings:

   • Uses 4.5L water + 4.5L glycol mix for eco-friendly heat transfer.

   • Stepless fan control (1000–1500 m³/h) reduces noise (49 dB indoor).

4. Flexible Deployment:

   • Outdoor unit handles 0°C–45°C temperatures; place it 20m away via lightweight hoses.

   • GMCC compressor and R32/R410A refrigerant ensure reliability.

5. Smart Control:

   • LCD display with real-time diagnostics, thermostat, and alarm alerts.

Technical Specifications

FAQ

Q: How does this differ from standard portable ACs?
A: Traditional units exhaust indoor air, reducing efficiency. The WXWSCT-7 uses a closed water-loop system, retaining cooled air and cutting energy use.

Q: Is ductwork needed?
A: No ducts required. Only two quick-connect hoses (included) link the indoor/outdoor units.

Q: What’s the maximum hose length?
A: Supports up to 20m total (5m or 15m hoses provided).

Q: Can it cool a server room?
A: Yes! Its 24,000 BTU output and precise thermostat (8°C–35°C) protect sensitive equipment.

Q: How loud is the outdoor unit?
A: 67 dB(A) (like a dishwasher). Position it remotely via hoses to minimize noise.
