Place of Origin:
Shanghai
Brand Name:
Weixuan
Certification:
CE, ISO
Model Number:
WX65
New innovation
1. Models for outdoor exhaust: Can be connected to outdoor by using the
2. separately sold exhausted duct.
3. Compact: Compact design without worrying about the placement area.
4. Super compact: Super compact design, with a placement area of 0.168m2
5. Little Drain: Up-to-date structure integrated with heat exchanger Significant
6. decrease in drain
7. Snug to wall: Can be placed close to the wall on three sides.
8. Air filter: Easy-to-clean air filter.
9. Durable filter: Large surface area, with no necessary to be frequently maintained.
10. Built-in auto swing mechanism: An auto swing mechanism is built in the unit.
Technical data
|
Model |
WX65 |
|
|---|---|---|
|
Capacity Data |
Cooling Capacity (BTU/HR) |
22,000 |
|
|
Cooling Test Conditions (F) |
95 DB/83 WB |
|
Electrical Data |
Voltage/Phase/Hertz |
220/1/50 |
|
|
Amperage |
8.4 |
|
|
Fuse Size* (Amps) |
10.8 |
|
Refrigerant |
Type |
R410A |
|
Unit Dimensions |
Height (MM) |
1100 |
|
|
Width (MM) |
630 |
|
|
Depth (MM) |
560 |
|
Weight |
Net Weight (KG) |
100 |
|
|
Shipping Weight (KG) |
120 |
|
Condensate Tank |
Capacity (L) |
14 |
Spot Cooler Rental Services
Service provides these portable coolers quickly and ready to rent on-demand and installs them on-site. Upon your request our technicians deliver the portable ac units, wheel them into place and assemble the necessary duct through the drop ceiling or wall, and will come prepared with the accessories to ensure the setup minimal interruption to your facility’s daily operations.
Power Cord Holder
1. Take out the cord holder from the accessory box.
2. Place the cord holder on the back side of air conditioner.
3. Use screws (enclosed inside of accessory box with cord holder) to install the cord holder on the air conditioner as shown in
Top Fan Exhaust Flange
1. Remove the top fan exhaust flange from carton.
2. Place the top fan exhaust flange on the top of air conditioner.
3. Use screws (enclosed inside of box with the top fan exhaust flange) to install the top fan exhaust flange on air conditioner as shown in Figure 5.
